Single Phase Undervoltage Relay 3 LEDs For Status Indication 440VAC SVRD-220

1 , over-voltage protection: When the grid voltage is greater than the set value starts the protection function, the action threshold setting range OFF-390-490V, action mode is definite time, action time setting range 0.1-25s. After the protection action, the grid voltage returns to less than the set value of 10V or more.

2 . Undervoltage protection: When the grid voltage is lower than the set value, it starts the protection function, the action threshold setting range is 300-370V-OFF, the action mode is the definite time limit, and the action time setting range is 0.1-25s. After the protection action, the grid voltage returns to more than 10 V above the set value.

♦ Features

-- Single-phase monitoring of over- and undervoltage

-- Powered by the measuring circuit

-- 2 C/O contacts

-- 3 LEDs for status indication

♦ Protective Functions

-- Overvoltage

-- Undervoltage

♦ Typical Applications

• Pumps • Fans

• Blowers • Motors

• Compressors

♦ Approvals

• CE • CCC

♦ Technical data
