    Terminal Block Interface Breakout Module , 40 Fujitsu / FCN Connector Terminal Boards

    Ask Lasest Price
    Brand Name : GINRI
    Model Number : JR-40TFC
    Certification : CE,CCC
    Payment Terms : L/C, T/T, Western Union,Paypal
    Supply Ability : 20000Pcs per month
    Delivery Time : 1-30 days upon order quantity
    • Product Details
    • Company Profile

    Terminal Block Interface Breakout Module , 40 Fujitsu / FCN Connector Terminal Boards

    Terminal Block Interface Breakout Module , 40 Fujitsu / FCN Connector Terminal Boards


    The I/O interface chip has one or more ports. One port corresponds to a register or a set of registers in the interface chip. The computer system allocates an address for each port. The address of each port is unique and cannot be duplicated. In the process of information transmission, the interface functions as data latching, data buffering, input/output, communication, data conversion, interrupt management, timing control, programmable, and electrical appliance feature matching.


    ♦ Features

    -- Support most of PLC output interface-- Standard DIN rain mounted-- High quality connectors with excellent stability-- Models available with Phillips screw, slotted screw-- Greatly savings in wiring and wiring Work-- Easy for inspection and maintenance-- Compact slim 49mm width• Micro-controller • PLC control • Servo System• Electro-magnetic valve • DC Motors • CNC machine

    • Home intelligent control


    Terminal blocks, also known as terminals , mainly play the role of electrical connections.

    With the development of social science and technology, the application of terminal blocks will become more and more extensive, such as where there are PCB printed circuit boards, etc., will be used This type of terminal block.


    ♦ Technical data

    ModelJR-40TFC
    Connector typeFujitsu
    I/O poles50
    Wiring method

    Euro terminal (slotted screws)

    *Japanese terminal (Phillips screws) can be customized

    Rated current1A
    Rated voltageDC24V
    Insuration resistance100MΩ min. (at 500VDC)
    Dielectric strength500VAC 1min
    Ambient operating temperature-20~+55
    Applicable wiresAWG 22-16(0.3~1.25mm2),6~7mm
    Suitable UsesMitsubish MR-E,COPLEY driver,Fuji ALPHA5 controller
    Dimensions(LxWxH)49×44mm
    MountingDIN rail
